Product Summary

The RF109-12 is a fully integrated transceiver device. It provides the transmit, receive, and frequency synthesis functions for 2400 MHz digital spread spectrum systems operating in the 2400–2483.5 MHz portion of the ISM (Industrial, Scientific, Medical) band.

Parametrics

Absolute maximum ratings: (1)Supply voltage:–0.3V to 5V; (2)Input voltage range1:–0.3V to VCC; (3)Power dissipation:700 mW; (4)LNA input power:+5 dBm; (5)Operating temperature range:–10℃ to 70℃; (6)Storage temperature:–40℃ to 125℃.

Features

Features: (1)Low power dissipation; (2)Fast settling from standby mode to active mode; (3)Separate enable lines for transmit, receive,and synthesizer; (4)64 programmable channels with 1.8 MHz channel spacing; (5)3-battery-cell operation; (6)48-pin TQFP package with exposed paddle.
